Mit-M 30-Gallon Two Stage Diesel Combination designed for the agricultural, construction and industrial industries, the 30-gallon air compressor/generator is powered by a diesel engine. This machine fits on the back of a service truck for big jobs in remote locations

Compressor Pump:Splash lubricated Stainless-steel braided discharge hose Large canister intake filter Oil level sight indicator

Generator:Brushless alternator Total harmonic distortion (THD) less than 6% 100% copper windings Comes standard with (2) 120V, 20A and (1) 240V, 20A receptacles

Engine:Electric start – battery, box and cables not included Glow plug equipped for easy starting in cold temperatures

Frame:Powder coated ASME coded 30-gallon receiver tank 3/16-inch base plate to reduce vibration 16-gauge powder coated two-piece belt guard

Components:Regulator and two gauges for tank and outlet pressure Manual drain valves for proper maintenance 16 -inch fly wheel Quality pilot valve unloader

*Equipped with 150-PSI maximum rated regulator

Specifications

• CFM @ 90 PSI

  16.4

• CFM @ 175 PSI*

  15.7

• Alternator Wattage: Max. Output

  3000 watts

• Alternator Wattage: Cont. with Comp. On-Load

  2300 watts

• Alternator Wattage: Cont. with Comp. Off-Load

  2750 watts

• Receptacles

  (2) NEMA 5-20R; (1) NEMA L6-20R

• Horsepower/Engine

  9.1 HP Kohler KD440 OHV

• Compressor

  Two Stage, Cast Iron

Weights & Dimensions

• Net Weight

  489.00 lbs.

• Shipping Weight

  554.00 lbs.

• Length

  41.00 in.

• Width

  23.00 in.

• Height

  47.00 in.

Options

• IX-0001 Vibration Isolator Pads

  Isolators protect the unit from vibration during use; recommended for models that are mounted in service truck applications

• AX-0070 Battery Tray, Box and 2-Foot of Cables

  Attaches to engine side of unit
